902～928MHz UHF RFID Antenna 9dBic Linear Polarization Connector Type N-50KFD IP67

Name: 902928MHz UHF RFID Antenna 9dBic Linear Polarization Connector Type N50KFD IP67
Brand: broadradio
Price: 1 USD

Wholesale 902～928MHz UHF RFID Antenna 9dBic Linear Polarization Connector Type N-50KFD IP67 from china suppliers

Brand Name : broadradio

Model Number : BRA-01L

Place of Origin : China Shenzhen

MOQ : 2pcs

Price : Negotiable

Payment Terms : T/T, PayPal

Delivery Time : 3-5 work days

Packaging Details : Standard Export Carton, Foam and Protective Film

Name : UHF RFID Antenna, Linear Polarization Antenna

Frequency Range : 902MHz～928MHz

VSWR : ≤1.3:1

Gain : > 9 dBic

H side HPBW : 70°

Polarization : Linear Polarization

Contact Now

BRA-01L 902～928MHz 9dBic Linear Polarization RFID Antenna,Connector Type N-50KFD IP67

Broadradio is a high-tech enterprise (national high-tech enterprise, Shenzhen high-tech enterprise) specializing in R&D, production and sales of RFID hardware products, including UHF RFID antenna, RFID electronic tag, RFID access control, rfid handset, Rfid reader, rfid smart file cabinet, RF cable, etc. With excellent independent innovation ability and professional technical team, it has obtained more than 100 national patents and PCT international patents.

Product Features

1)BRA-01L Antenna is of convenient application in access control, warehousing, logistics, retail and other UHF RFID application fields.

2)Electrical Properties: It is a general antenna for UHF RFID applications with high gain and low VSWR.

3)Mechanical Properties: pleasing appearance with small size, double waterproof design with waterproof ring and silica gel, rib reinforcement design for shell, suitable for various severe environments.

902～928MHz UHF RFID Antenna 9dBic Linear Polarization Connector Type N-50KFD IP67

Mechanical Specifications

Size	258mm×258mm×36mm
Weight	0.91kg (bracket excluded)
Material	Engineering plastics ASA, aluminum
Color	Milk-white
Production Class	IP67
Operating Temperature	-40℃~+ 85℃
Storage Temperature	-40℃~+ 85℃
Relative humidity	5%～95%
Impedance	50±1Ω
Connector Type	N Female

902～928MHz UHF RFID Antenna 9dBic Linear Polarization Connector Type N-50KFD IP67

Packaging accessories

Host: BRA-01L antenna

Accessories: L plate (mounting bracket), dog teeth, M6 U-bolt, M6 nut, spring washer, flat washer
